Technical specifications
| Frame
|
STEEL
|
| Fork
|
ZOOM 386A EN, 29"x28.6 OVERSIZEx250mm, THREADLESS
|
| Head parts
|
NECO, 846BK, 1-1/8" AHEAD
|
| Handlebar
|
ZOOM MTB-153TP, STEEL, RAISED 30mm, BEND 10deg, 620mm
|
| Handle stem
|
ZOOM, TDS-C41-8 (ISO-M), EXT 90mm.x28.6mm,+10 DEG., HEIGHT 41mm
|
| Brakes
|
JAK - 8, FRONT AND REAR DISC BRAKE SET
|
| Crank set
|
SUNTOUR CW14 XCC-T102 PB IBG SQ BB:122, 42X34X24T, 170mm
|
| Pedals
|
XERAMA SP-872N ONE PIECE PP BODY
|
| Front derailleur
|
SHIMANO, FD-TZ500-DS6, FOR 3(FRICTION)X7/6, DOWN-SWING, TOP-PULL, 28.6MM BAND, CS-ANGLE:66-69, FOR TOP GEAR:42T, CL:47.5MM
|
| Rear derailleur
|
SHIMANO, RD-TY300, TOURNEY, 6/7-SPEED, DIRECT ATTACHMENT TYPE, BULK
|
| Freewheel
|
SHIMANO, MULTIPLE FREEWHEEL SPROCKET, MF-TZ500-7,7-SPEED, 14-16-18-20-22-24-28T
|
| Shifters
|
SHIMANO, SL-RS35
|
| Chain
|
KMC, HV-500, 1/2"x3/32"
|
| Wheel
|
WHEEL 28"-622 Mach1-MC40
|
| Tires
|
KENDA ATB 700x50C
|
| Saddle
|
ACTIVE FM-253
|
| Seat post
|
SEAT POST, STEEL, 25.4x300x1,4T, THREADED, ED
|
| Wheel size
|
28"
|
| Weight
|
16.9 kg
|
Geometry
|
