| Frame
|
ALLOY
|
| Fork
|
SUNTOUR SF13-XCT- JR-P 24"x28.6x183mm
|
| Headset
|
NECO, H117DM, 1-1/8" AHEAD, ST, 44/50mm
|
| Handle stem
|
ZOOM, TDS-C41-8 (ISO-M), EXT: 75mmx28.6mm, +15 DEG., HEIGHT 41mm
|
| Handlebar
|
LOGAN, EH-N412K, STEEL, RAISED 30mm, BEND 6 deg, W: 580mm, 1.8mm
|
| Brakes
|
PROMAX TX-121, ALLOY V-BRAKE
|
| Crank set
|
SHIMANO, FC-TY301, FOR REAR 6/7/8-SPEED, 150MM, 42X34X24T W/CG
|
| Pedals
|
XERAMA SP-872N ONE PIECE PP BODY
|
| Front derailleur
|
SHIMANO FD-TY700-TS, 31.8mm, 66-69, 42T
|
| Rear derailleur
|
SHIMANO, RD-TX800, TOURNEY TX, 7/8-SPEED, DIRECT ATTACHMENT TYPE
|
| Freewheel
|
SHIMANO, CS-HG41, 11-32T(AW), 8 SPEED
|
| Chain
|
KMC, Z8.3, 1/2"x3/32
|
| Shifters
|
SHIMANO SL-M315
|
| Wheel
|
WHEEL 24"-507 Mach1-810
|
| Tires
|
KENDA MTB 24x1.95
|
| Saddle
|
BASSANO MITO JUNIOR
|
| Seat post
|
ZOOM, SP-C208, 27.2x300mm
|
| Wheel size
|
24"
|
| Weight
|
13.2 kg
|
|
