| Frame
|
KnK
|
Gents/Trapez/Wave alloy semi
|
| Fork
|
suntour
|
CR7V
|
|
| Frame Height
|
Gents: 56 cm
|
| Front Hub
|
Shimano
|
Dynamohub DH-C 3000 nutted, black
|
ADHC30001NDNL
|
| Rear Hub
|
Shimano
|
FH TX 500/8, nutted BLACK
|
AFHTX5008DL
|
| Rims
|
SCHURMANN
|
YAK 622-21 SW/ 36L/ ABR, SLD:4,5/VLD:8,5 - O.LOGO
|
| Spokes
|
SP
|
With ED black Spokes Import China
|
| Nyples
|
SP
|
Messing/Brass
|
| Tyres
|
RALSON
|
R-3155 URBAN LEGEND ETRTO 47-622 BLK WITH REFLEX TAPE
|
| Tube
|
RALSON
|
Tube 28x1.75 with Dunlop Valve 40mm, Butyl
|
| Rim Tape
|
MITAS
|
HP 20 mm
|
| Chainwheel
|
Shimano
|
FC-TY 301
|
AFCTY301C888XL
|
| BB
|
THUN
|
KB full cartridge, 122,5mm
|
IBEX 123mm
|
| Chainguard
|
Herrmans
|
Slyde, black
|
| Headset
|
FEIMIN
|
FP-H815A - MTB HEAD PARTS , THREADED HEAD SET 10pcs, BC1-1/8"X26tpi, 25.4x44X30MM, 17.7+3=20.7, WITH KEY WASHER, FINISH: BLACK, WITH COVER H815, Steel ED
|
| Brakes
|
Promax
|
TX123 front and rear
|
| Rotor
|
|
|
|
| Brake Lever
|
Shimano
|
ST-TX 800, 3/8, black
|
ASTTX800LBL
|
| Shifter
|
Shimano
|
ST-TX 800, 3/8, black
|
ASTTX800R8DL
|
| Rear Derailleur
|
Shimano
|
Altus, RDM 310
|
ARDM310DL
|
| Front Derailleur
|
Shimano
|
FD-TY 710
|
AFDTY710TSM6
|
| Chain
|
KMC
|
Z 72 with link
|
| Sprocket
|
Shimano
|
CS-HG 200/8, 12-32 teeth
|
ACSHG2008232T
|
| Mudguards
|
EUROFENDER
|
plastik black shiny, 58 mm
|
| Mudguard End
|
Mudflap rear
|
| Stays
|
|
V-stays with safety clip front
|
| Carrier
|
MASSLOAD
|
Massload HA-003-3B
|
| Pump
|
|
|
|
| Lock
|
|
|
|
| Handlebar
|
Promax
|
alloy Taper Shape Bar Bore 31,8mm, Rise 18/30mm, Back sweep 9°, W=620mm, SBBK, Model HB-3188
|
| Stem
|
Promax
|
MQ-570S-85 Alloy adjustable, black/SBBK 31,8 / MQ-570-5 105 Alloy adjustable, black
|
| Bar Ends
|
|
|
|
| Grips
|
VP
|
VP Tour Wing Eco 0318228M
|
| Rear Light
|
Trentmann
|
CONTEC TL-135 61000001
|
| Reflector Rear
|
w/o
|
|
| Front Light
|
Trentmann
|
CONTEC DLUX 30 N++ 61010003
|
| Reflector Front
|
|
|
| Pedal
|
MARWI
|
Marwi SP-827 VIC bl 326718 0.336.090/M
|
| Saddle
|
Selle Royal
|
3060 H/ D
|
|
| Seatpost
|
Promax
|
SP-222 Alloy patent 27,2x350 black matt
|
| Bell
|
Import/Büchel
|
Mini Bell black
|
| Kickstand
|
URSUS
|
Easy No. 92 - black
|
| Seatclamp
|
HL
|
Zoom, black, NO QR AT-83, DIA 31.8MM, BLACK
|
| Packing
|
|
BOX 28"
|
|
| Painting
|
KRIPTON
|
powder paint
|
| Decal
|
POSTERAMA
|
decal under clearcoat/ai file ex Soeckneck
|
| Manual
|
|
|
|
| Others
|
|
Niro Inbus screws/washers, laying cable in carrier stay, inner cable routing
|
|
